V100

Date of issue:2021/9/23 9:33:38 Number of Views:


Specification type:V100

· rated flow:100m³ /h

· extreme vacuum:0.1~0.5 mbar

· motor power :3 kW

· rated voltage:380 V / 50HZ

· Suction diameter:G1 1/4"

· rated speed:1440r/min

· noise level:≤ 67dB

· fuel consumption:2.5L

· machine weight:85 kg

· profile size (length * Width * Height):715*410*295mm

product description

V-series single-stage Rotary Vane vacuum pump is a basic type of vacuum equipment using oil circulation lubrication, air-cooled type durable, reliable and economic for the removal of ordinary air or a small amount of condensable gas

For a wide range of industrial applications in the coarse-low vacuum range.

Product characteristics

Standard Motor direct drive, can be customized special requirements motor structure compact and light, especially suitable for equipment equipped with suction outlet using standard thread, connection convenient equipped with high-efficiency oil and gas separation device, exhaust clean

Smooth and quiet operation, no special fixed or shock absorber reliable oil circulation structure, suitable for long-term continuous operation, easy installation and maintenance, low operating costs.

 Typical application

Thermoforming (plastic suction, air pressure, foaming) molding

Vacuum packaging equipment and food processing

Vacuum degassing, defoaming, infiltration, concentration, drying

Vacuum Adsorption, fixture, sling, Suction Cup

Vacuum pressing, setting, film sticking

Vacuum crystallization, distillation, injection, cooling

Suitable for the industry

Vacuum packaging and food processing machinery

Vacuum forming-forming equipment

Vacuum drying and filtering equipment

Equipment for degassing and soaking of materials

Vacuum of mould cavity

Vacuum manipulator or worktable, etc.

Small and medium-sized mobile vacuum station



Specification type:V100

· rated flow:100m³ /h

· extreme vacuum:0.1~0.5 mbar

· motor power :3 kW

· rated voltage:380 V / 50HZ

· Suction diameter:G1 1/4"

· rated speed:1440r/min

· noise level:≤ 67dB

· fuel consumption:2.5L

· machine weight:85 kg

· profile size (length * Width * Height):715*410*295mm

product description

V-series single-stage Rotary Vane vacuum pump is a basic type of vacuum equipment using oil circulation lubrication, air-cooled type durable, reliable and economic for the removal of ordinary air or a small amount of condensable gas

For a wide range of industrial applications in the coarse-low vacuum range.

Product characteristics

Standard Motor direct drive, can be customized special requirements motor structure compact and light, especially suitable for equipment equipped with suction outlet using standard thread, connection convenient equipped with high-efficiency oil and gas separation device, exhaust clean

Smooth and quiet operation, no special fixed or shock absorber reliable oil circulation structure, suitable for long-term continuous operation, easy installation and maintenance, low operating costs.

 Typical application

Thermoforming (plastic suction, air pressure, foaming) molding

Vacuum packaging equipment and food processing

Vacuum degassing, defoaming, infiltration, concentration, drying

Vacuum Adsorption, fixture, sling, Suction Cup

Vacuum pressing, setting, film sticking

Vacuum crystallization, distillation, injection, cooling

Suitable for the industry

Vacuum packaging and food processing machinery

Vacuum forming-forming equipment

Vacuum drying and filtering equipment

Equipment for degassing and soaking of materials

Vacuum of mould cavity

Vacuum manipulator or worktable, etc.

Small and medium-sized mobile vacuum station
